Description
| Specification | |
|---|---|
| Operating System | Android 10 |
| Processor | Qualcomm SDM660 Octa-core Processor (2.2GHz) |
| Memory | 4GB RAM & 128GB On-board Memory |
| Display | 10.1-inch LED capacitive touchscreen with 1920×1200 resolution |
| Connectivity | Wi-Fi (802.11 a/b/g/n/ac); USB: 2.0; BT v.2.1 + EDR; SD Card (Support up to 64GB); HDMI |
| Sensors | Light sensor for brightness auto adjust |
| Power and Battery | 15000 mAh 3.8 V lithium-polymer battery Charging via 12 V AC/DC power supply |
| Input Voltage | 12 V (9-24 V) |
| Power Consumption | 6.5 W |
| Operating Temp. | 0 to 50°C (32 to 122°F) |
| Storage Temp. | -20 to 60°C (-4 to 140°F) |
| Dimensions (W x H x D) | 300 mm (11.81”) x 220 mm (8.66”) x 50 mm (1.97”) |
| Net Weight | NW: 1.58 kg (3.48 lb.) |
| Supported Automotive Protocols | ISO 9142-2, ISO 14230-2, ISO 15765-4, K/L-Line, Flashing Code, SAE-J1850 VPW, SAE-J1850 PWM, CAN ISO 11898, Highspeed, Middlespeed, Lowspeed and Singlewire CAN, GM UART, UART Echo Byte Protocol, Honda Diag-H Protocol, TP 2.0, TP 1.6, SAE J1939, SAE J1708, Fault-Tolerant CAN |
