Description
| Feature | Details |
|---|---|
| Recommended Use | Indoor |
| Operating System | Android™ 4.4.4, KitKat |
| Processor | Cortex-A9 processor (1.6 GHz) |
| Memory | 64GB |
| Display | 7-inch LCD capacitive touchscreen with 1024×600 resolution |
| Connectivity | Mini USB 2.0, USB 2.0, Wi-Fi, HDMI Type A, Micro SD card slot (supports up to 32GB) |
| Sensors | Light sensor for brightness auto-adjust |
| Audio Input/Output | Input: N/A Output: Buzzer |
| Power and Battery | 3.7 V/5000 mAh lithium-polymer battery Charges via 5 VDC power supply |
| Tested Battery Life | Around 7 hours of continuous use |
| Battery Charging Input | 5V/1.5A |
| Power Consumption | 600 mA (LCD on with default brightness, Wi-Fi on) @ 3.7 V |
| Operating Temp | -10 to 60°C (14 to 140°F) |
| Storage Temp | -20 to 70°C (-4 to 158°F) |
| Operating Humidity | 5% – 95% non-condensing |
| Dimensions (WxHxD) | 270.8 mm (10.0) x 176.0 mm (6.9) x 36.0 mm (1.4) |
| Net Weight | 885 g (2.31 lb.) |
| Protocols | ISO9141-2, ISO14230-2, ISO15765, K/L-Line, Flashing Code, SAE-J1850 VPW, SAE-J1850 PWM, ISO11898 (Highspeed, Middlespeed, Lowspeed, Singlewire CAN, fault-tolerant CAN), SAE J2610, GM UART UART Echo Byte Protocol, Honda Diag-H Protocol, TP2.0, TP1.6 |
